Solutions Aluminum Railing Kits

Stylish, Sculpted Top Rail
No Exposed Pop Rivets or Screws Where Balusters Meet Rail
Convenient Kits
36" or 42" Railing Heights
4', 6' and 8' Rail Lengths for Level and Stair installations
Durable Aluminum
Meets ASTM E935 and E985 Standards
Built to Last
Lightweight Materials
Tough, Powder Coated Finish
AAMA-2604-05 Compliant
Powder Coated Aluminum
Quick Installation
Easy to Install
15 Year Warranty
Round, Square or Glass Balusters

Available Colors

White Bronze Black

Installation Instructions

Parts Needed for Complete Railing
Kits Include Top & Bottom Rail Balusters Bottom Brackets (top Brackets Sold Separately) Rail Support	Level Rail Kit	- 4', 6' or 8' with Aluminum or Glass Balusters
	Stair Rail Kit	- Adjustable Stair or Fixed Stair in 36" or 42" Heights
	Post Skirts & Sleeves	- Structural Mounts & Post Sleeves w/caps and base trim
	Bracket Kits	- Top Brackets needed for Installation

RAIL KITS

LEVEL RAIL KITS w/Aluminum Balusters

4' x 36"

$102.53

Includes 10 Balusters

Black, Bronze or White

6' x 36"

$153.77

Includes 15 Balusters

Black, Bronze or White

8' x 36"

$205.00

Includes 21 Balusters

Black, Bronze or White

4' x 42"

$131.65

Includes 10 Balusters

Black, Bronze or White

6' x 42"

$197.44

Includes 15 Balusters

Black, Bronze or White

8' x 42"

$263.24

Includes 21 Balusters

Black, Bronze or White

LEVEL RAIL KITS w/Glass Balusters

4' x 36"

$214.76

Includes 6 - 4" Glass Balusters

Black, Bronze or White

6' x 36"

$322.17

Includes 9 - 4" Glass Balusters

Black, Bronze or White

8' x 36"

$429.51

Includes 12 - 4" Glass Balusters

Black, Bronze or White

4' x 42"

$236.24

Includes 6 - 4" Glass Balusters

Black, Bronze or White

6' x 42"

$354.40

Includes 9 - 4" Glass Balusters

Black, Bronze or White

8' x 42"

$472.28

Includes 12 - 4" Glass Balusters

Black, Bronze or White

STAIR RAIL KITS w/Aluminum Balusters

4' x 36" Adjustable

$143.11

Includes 9 Balusters

Adjusts from 5 to 38 Degrees

6' x 36" Adjustable

$214.61

Includes 14 Balusters

Adjusts from 5 to 38 Degrees

8' x 36" Adjustable

$286.13

Includes 18 Balusters

Adjusts from 5 to 38 Degrees

4' x 36" Fixed

$108.55

Includes 9 Balusters

Fits 30 to 34 Degrees

6' x 36" Fixed

$162.81

Includes 9 Balusters

Fits 30 to 34 Degrees

8' x 36" Fixed

$217.01

Includes 9 Balusters

Fits 30 to 34 Degrees

4' x 42" Adjustable

$180.41

Includes 9 Balusters

Adjusts from 5 to 38 Degrees

6' x 42" Adjustable

$270.65

Includes 14 Balusters

Adjusts from 5 to 38 Degrees

8' x 42" Adjustable

$360.82

Includes 18 Balusters

Adjusts from 5 to 38 Degrees

4' x 42" Fixed

$141.07

Includes 9 Balusters

Fits 30 to 34 Degrees

6' x 42" Fixed

$189.11

Includes 9 Balusters

Fits 30 to 34 Degrees

8' x 42" Fixed

$252.07

Includes 9 Balusters

Fits 30 to 34 Degrees

STAIR RAIL KITS w/Glass Balusters

4' x 36"

$256.80

Includes 5 - 4" Glass Balusters

Adjusts from 5 to 38 Degrees

6' x 36"

$385.13

Includes 8 - 4" Glass Balusters

Adjusts from 5 to 38 Degrees

8' x 36"

$513.53

Includes 10 - 4" Glass Balusters

Adjusts from 5 to 38 Degrees

4' x 42"

$282.45

Includes 5 - 4" Glass Balusters

Adjusts from 5 to 38 Degrees

6' x 42"

$423.72

Includes 8 - 4" Glass Balusters

Adjusts from 5 to 38 Degrees

8' x 42"

$564.91

Includes 10 - 4" Glass Balusters

Adjusts from 5 to 38 Degrees

POST MOUNTS AND SLEEVES

There are 2 options available for the post mounts for your aluminum railing system. If you have 4x4 wood posts already installed on your deck, simply slip the 4" Post Sleeve over your wood post and mount your railings to your post sleeve. If you don't have posts, you can use either the 1 7/8" Post Mounts or the 3 1/2" Post Mount, or a combination of the 2. If you use the 1 7/8" Post Mount (see installation instructions for mounting procedures), you will need the 1 7/8" Post Sleeve to fit over the Mount. The 3 1/2" Post Mounts does not need a post sleeve. For more information, or for help planning your aluminum railing system, let the experts at Deck Builder Outlet guide you. Call 800-966-9261

4 x 4 Post Sleeves
Fits over Wood 4x4
39"	$33.57
44"	$40.21

3 1/2" x 3 1/2" Post Mount w/Flange
For Post to Post Installations
38"	$55.83
44"	$60.84
54"	$75.05

1 7/8" x 1 7/8" Post Sleeve
Fits over 1 7/8" Post Mount
34"	$18.66
39"	$19.57
54"	$26.21

1 7/8" x 23 1/4" Post Mount

For Over the Post Installations

4" Base Plaste

$29.27

POST CAPS AND BASE TRIM

Post Caps
1 7/8"	$4.67
3 1/2"	$4.67
4"	$6.43

Post Base Trim
1 7/8"	$5.65
3 1/2"	$8.13
4"	$8.13

BRACKETS

All Solutions Aluminum Rail Kits include the bottom rail brackets which will mount to any of the post sleeves & post mounts, or to any level surface like your home or brick or concrete pillars. To complete your installation, you will need to purchase the appropriate upper bracket. These brackets fall into 2 categories, Post to Post (PTP) or Over the Post (OTP). The PTP brackets mount to the side of the post sleeve, post mount or vertical surface where the OTP brackets mount atop the 1 7/8" post sleeve. Multi-Pitch Stair Brackets allow for 5 - 38 Degree variances, Multi-Angle Brackets allow up to 90 Degrees turns.

Post To Post (PTP) Brackets
